The X5200 UVIR Flame Detector meets the most stringent requirements worldwide with advanced detection capabilities and immunity to extraneous sources, combined with a superior mechanical design.

The mounting arrangement allows the UV and IR sensors to monitor the same hazardous location with a 90 degree cone of vision.

When both sensors simultaneously detect the presence of a flame, an alarm signal is generated.

The detector has Division and Zone explosion-proof ratings and is suitable for use in indoor and outdoor applications.

The standard output configuration includes fire, fault and auxiliary relays.

An optional 0 to 20 mA output with HART can be provided in addition to the three relays.

A model with pulse output is available for easy retrofitting into existing Det-Tronics controller based systems.

Auxiliary relay and 0 to 20 mA output are not available with the pulse model.

A tri-color LED on the detector faceplate indicates normal condition and notifies personnel of fire alarm or fault conditions.

The X5200 housing is available in aluminum or stainless steel, with NEMA 4X and IP66/IP67 rating.
